# LED Behavior

### <img src="https://3007253866-files.gitbook.io/~/files/v0/b/gitbook-legacy-files/o/assets%2F-MRz1UmXtli7_tY_lfcZ%2F-MT4f0QQvSXaBdf07RB8%2F-MT4gdjg8BQNRi6qQl19%2Ficon.png?alt=media&#x26;token=a6a7915f-834d-408b-9197-db00c5b6a22b" alt="" data-size="line"> **EWS1200-28TFPv2/ EWS7928Pv2/ EWS7952FPv3**

{% tabs %}
{% tab title="Copper Port" %}

| LED           | **Behavior** | **Description**                   |
| ------------- | ------------ | --------------------------------- |
| **LAN Mode**  | Solid light  | Speed 1000Mbps                    |
| **LAN Mode**  | Light off    | Speed 10Mbps/100Mbps              |
| **PoE Mode**  | Solid light  | Power feeding                     |
| **Poe Mode**  | Light off    | No power feeding                  |
| **Link/ Act** | Solid light  | Link                              |
| **Link/ Act** | Blinking     | Transmit or receive  on this port |
| **Link/ Act** | Light off    | No link                           |
| {% endtab %}  |              |                                   |

{% tab title="SFP Port" %}

| LED           | **Behavior** | **Description**                   |
| ------------- | ------------ | --------------------------------- |
| **Speed**     | Solid light  | Speed 1Gbps                       |
| **Speed**     | Light off    | No link/ Speed 100Mbps            |
| **Link/ Act** | Solid light  | Link                              |
| **Link/ Act** | Blinking     | Transmit or receive  on this port |
| **Link/ Act** | Light off    | No link                           |
| {% endtab %}  |              |                                   |
| {% endtabs %} |              |                                   |

### <img src="https://3007253866-files.gitbook.io/~/files/v0/b/gitbook-legacy-files/o/assets%2F-MRz1UmXtli7_tY_lfcZ%2F-MT4f0QQvSXaBdf07RB8%2F-MT4gdjg8BQNRi6qQl19%2Ficon.png?alt=media&#x26;token=a6a7915f-834d-408b-9197-db00c5b6a22b" alt="" data-size="line"> **EWS7952Pv2**

{% tabs %}
{% tab title="Copper Port" %}

| LED           | **Behavior** | **Description**                   |
| ------------- | ------------ | --------------------------------- |
| **LAN Mode**  | Solid light  | Speed 1000Mbps                    |
| **LAN Mode**  | Light off    | Speed 10Mbps                      |
| **PoE Mode**  | Solid light  | Power feeding                     |
| **Poe Mode**  | Light off    | No power feeding                  |
| **Link/ Act** | Solid light  | Link                              |
| **Link/ Act** | Blinking     | Transmit or receive  on this port |
| **Link/ Act** | Light off    | No link                           |
| {% endtab %}  |              |                                   |

{% tab title="SFP Port" %}

| LED           | **Behavior**      | **Description**                   |
| ------------- | ----------------- | --------------------------------- |
| **Speed**     | Green solid light | Speed 1Gbps                       |
| **Speed**     | Amber solid light | Speed 100Mbps                     |
| **Link/ Act** | Solid light       | Link                              |
| **Link/ Act** | Blinking          | Transmit or receive  on this port |
| **Link/ Act** | Light off         | No link                           |
|               |                   |                                   |
| {% endtab %}  |                   |                                   |
| {% endtabs %} |                   |                                   |

###

### <img src="https://3007253866-files.gitbook.io/~/files/v0/b/gitbook-legacy-files/o/assets%2F-MRz1UmXtli7_tY_lfcZ%2F-MT4f0QQvSXaBdf07RB8%2F-MT4gdjg8BQNRi6qQl19%2Ficon.png?alt=media&#x26;token=a6a7915f-834d-408b-9197-db00c5b6a22b" alt="" data-size="line"> **EWS2908P/ EWS2910Pv2/ EWS5912FPv2**

{% tabs %}
{% tab title="Copper Port" %}

| LED           | **Behavior**      | **Description**                   |
| ------------- | ----------------- | --------------------------------- |
| **LAN Mode**  | Green solid light | Speed 1000Mbps                    |
| **LAN Mode**  | Amber solid light | Speed 100Mbps                     |
| **LAN Mode**  | Light off         | Speed 10Mbps                      |
| **PoE Mode**  | Green solid light | Power feeding                     |
| **PoE Mode**  | Amber solid light | Error condition                   |
| **Poe Mode**  | Light off         | No power feeding                  |
| **Link/ Act** | Solid light       | Link                              |
| **Link/ Act** | Blinking          | Transmit or receive  on this port |
| **Link/ Act** | Light off         | No link                           |
| {% endtab %}  |                   |                                   |

{% tab title="SFP Port" %}

| LED           | **Behavior** | **Description**                   |
| ------------- | ------------ | --------------------------------- |
| **Link/ Act** | Solid light  | Link                              |
| **Link/ Act** | Blinking     | Transmit or receive  on this port |
| **Link/ Act** | Light off    | No link                           |
| {% endtab %}  |              |                                   |
| {% endtabs %} |              |                                   |
